WDR-480 series
September 27, 2023MW Mean Well Meanwell 240W Ultra Wide Input Industrial DIN Rail Power Supply WDR-240 Series
Features
- Single and two phase wide input range 180 – 550VAC
- Built-in active PFC circuit compliance to BS EN/EN61000-3-2
- High efficiency 91% and low power dissipation
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or15
- UL508(industrial control equipment)approved
- BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level
- 100% full load burn-in test
- Built-in DC OK relay contact
- 3 years warranty
Description
WDR-240 series is a 240W DIN rail power supply with ultra-wide AC input range. It is suitable to be mounted on TS-35/7.5 or TS-35/15 rails. Main features are as following: it can accept 180〜550Vac ultra-wide input voltage range for single phase or 2-phase system, easy to install DIN rail type, width (63mm) in slim design, -30〜+70°C wide range operating temp, 4.7KVAC high isolation voltage, operation at 2000m altitude, adjustable output voltage (+20% max.), high efficiency, low ripple & noise, complete protections and so on. WDR-240 is compliant with BS EN/EN-61000-6-2 standard regarding immunity for industrial environments. It suitable for industrial automation, surveillance, telecommunication and more applications.
Mean Well Power Supply WDR-240 Series Model Encoding
Mean Well Power Supply WDR-240 Series Data Sheet Download
Specification
| MODEL | WDR-240-24 | WDR-240-48 | |
|
OUTPUT |
DC VOLTAGE | 24V | 48V |
| RATED CURRENT | 10A | 5A | |
| CURRENT RANGE | 0 ~ 10A | 0 ~ 5A | |
| RATED POWER | 240W | 240W | |
| RIPPLE & NOISE (max.) Note.2 | 150mVp-p | 150mVp-p | |
| VOLTAGE ADJ. RANGE | 24 ~ 28V | 48 ~ 55V | |
| VOLTAGE TOLERANCE Note.3 | ±1.0% | ±1.0% | |
| LINE REGULATION | ±0.5% | ±0.5% | |
| LOAD REGULATION | ±1.0% | ±1.0% | |
| SETUP, RISE TIME | 800ms, 150ms/400VAC 1500ms, 150ms/230VAC at full load | ||
| HOLD UP TIME (Typ.) | 18ms / 400VAC 18ms / 230VAC at full load | ||
|
INPUT |
VOLTAGE RANGE Note.6 | 180 ~ 550VAC 254 ~ 780VDC | |
| FREQUENCY RANGE | 47 ~ 63Hz | ||
| POWER FACTOR (Typ.) | PF≥0.84/400VAC PF≥0.84/230VAC | ||
| EFFICIENCY (Typ.) | 91% | ||
| AC CURRENT (Typ.) | 1A/400VAC 2A/230VAC | ||
| INRUSH CURRENT (Typ.) | COLD START 50A | ||
| LEAKAGE CURRENT | <3.5mA / 530VAC | ||
|
PROTECTION |
OVERLOAD | 105 ~ 130% rated output power | |
| Protection type: Constant current limiting, unit will shut down after 3 sec., auto-recovery after 1 minute if the fault condition is removed | |||
| OVER VOLTAGE | 29 ~ 33V | 56 ~ 65V | |
| Protection type: Shut down o/p voltage, auto-recovery after 1 minute if the fault condition is removed | |||
| OVER TEMPERATURE | 90℃±5℃ (TSW) detect on heatsink of power switch | ||
| Protection type: Shut down o/p voltage, recovers automatically after temperature goes down | |||
| FUNCTION | DC OK REALY CONTACT RATINGS (max.) | 60Vdc/0.3A, 30Vdc/1A, 30Vac/0.5A resistive load | |
|
ENVIRONMENT |
WORKING TEMP. Note.5 | -30 ~ +70℃ (Refer to “Derating Curve”) | |
| WORKING HUMIDITY | 20 ~ 95% RH non-condensing | ||
| STORAGE TEMP., HUMIDITY | -40 ~ +85℃, 10 ~ 95% RH | ||
| TEMP. COEFFICIENT | ±0.03%/℃ (0 ~ 50℃) | ||
| VIBRATION | Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6 | ||
|
SAFETY & EMC (Note 4) |
SAFETY STANDARDS | UL508, EAC TP TC 004 approved, IEC62368-1 CB approved by SIQ, design refer to BS EN/EN62368-1, AS/NZS 62368.1,GL; (meet BS EN/EN60204-1) | |
| WITHSTAND VOLTAGE | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC O/P-DC OK:0.5KVAC | ||
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:>100M Ohms / 500VDC / 25℃/ 70% RH | ||
| EMC EMISSION | Compliance to BS EN/EN55032 (CISPR32), BS EN/EN61204-3 Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020 | ||
| EMC IMMUNITY | Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, BS EN/EN61000-6-2 (BS EN/EN50082-2), BS EN/EN61204-3,
heavy industry level, EAC TP TC 020 approved |
||
|
OTHERS |
MTBF | 1062.8K hrs min. Telcordia SR-332 (Bellcore); 141.1K hrs min. MIL-HDBK-217F (25℃) | |
| DIMENSION | 63*125.2*113.5mm (W*H*D) | ||
| PACKING | 1.06Kg; 12pcs/13.7Kg/1.22CUFT | ||
Applications
- Industrial control system
- Semiconductor fabrication equipment
- Factory automation
- Electro-mechanical apparatus
